VIVIX-S 3643VW

The VIVIX-S 3643VW (FXRD-3643VAW) is the 14″ x 17″ detector in Vieworks’ VIVIX-S V Series. Its standard-size imaging area covers chest, abdominal and spine studies in human and veterinary practice, and dual batteries provide up to 16 hours of standby. Wi-Fi and Gigabit Ethernet connectivity plus an IP67 rating make it a fit for fixed rooms and mobile work.

Key Features

• Standard 14″ x 17″ Imaging Area – A 35.8 x 43.0 cm active area with a 2560 x 3072 pixel matrix covers chest, abdominal and spine views.
• Clear, Consistent Images – A CsI scintillator and 140 µm pixel pitch deliver 3.5 lp/mm spatial resolution with 16-bit grayscale.
• Fast Image Acquisition – Images appear in 3 seconds, with a recommended cycle time of 4 seconds between exposures.
• Wired or Wireless Connection – Transfer images over IEEE 802.11n/ac Wi-Fi or Gigabit Ethernet to suit your room setup.
• Flexible Generator Integration – Run in DR Trigger Mode or AED Mode, so the detector can detect exposures automatically without a direct generator connection.
• Dual-Battery Power – Two 3,400 mAh lithium-ion batteries provide 16 hours of standby and up to 3,000 images at a 15-second cycle.
• Portable and Sealed – Measures 15.1 x 18.1 x 0.6 inches and weighs 6.5 lbs (2.95 kg) with one battery, with IP67 protection against dust and water.

Specifications

• Model Number: FXRD-3643VAW
• Imaging Area: 14″ x 17″ (35.8 x 43.0 cm)
• Pixel Pitch: 140 µm
• Spatial Resolution: 3.5 lp/mm
• Pixel Matrix: 2560 x 3072
• Dimensions: 15.1 x 18.1 x 0.6 in
• Weight: 6.5 lbs (2.95 kg) with 1 battery
• Battery: 2 x 3,400 mAh, 16 h standby, up to 3,000 images
• Ingress Protection: IP67
