VIVIX-S 4343VW

The VIVIX-S 4343VW (FXRD-4343VAW) is the full-field 17″ x 17″ detector in Vieworks’ VIVIX-S V Series. The square imaging area captures large anatomy without rotating the detector between views, and dual batteries provide up to 16 hours of standby. It connects over Wi-Fi or Gigabit Ethernet and carries an IP67 rating against dust and water.

Key Features

• Full-Field 17″ x 17″ Imaging Area – A 43.0 x 43.0 cm active area with a 3072 x 3072 pixel matrix captures large patients and wide anatomy in a single exposure.
• Clear, Consistent Images – A CsI scintillator and 140 µm pixel pitch deliver 3.5 lp/mm spatial resolution with 16-bit grayscale.
• Fast Image Acquisition – Images appear in 3 seconds, with a recommended cycle time of 4 seconds between exposures.
• Wired or Wireless Connection – Transfer images over IEEE 802.11n/ac Wi-Fi or Gigabit Ethernet to suit your room setup.
• Flexible Generator Integration – Run in DR Trigger Mode or AED Mode, so the detector can detect exposures automatically without a direct generator connection.
• Dual-Battery Power – Two 3,400 mAh lithium-ion batteries provide 16 hours of standby and up to 3,000 images at a 15-second cycle.
• Durable and Sealed – Measures 18.1 x 18.1 x 0.6 inches and weighs 7.6 lbs (3.45 kg) with one battery, with IP67 protection against dust and water.

Specifications

• Model Number: FXRD-4343VAW
• Imaging Area: 17″ x 17″ (43.0 x 43.0 cm)
• Pixel Pitch: 140 µm
• Spatial Resolution: 3.5 lp/mm
• Pixel Matrix: 3072 x 3072
• Dimensions: 18.1 x 18.1 x 0.6 in
• Weight: 7.6 lbs (3.45 kg) with 1 battery
• Battery: 2 x 3,400 mAh, 16 h standby, up to 3,000 images
• Ingress Protection: IP67
